BIOSTAR 8M 15-50mm 6-Lane Traffic
|
|
BIOSTAR 8M 15-50mm 6-Lane Traffic
-
Processor-socket
LGA 1700 (stik V)
-
Chipset
Intel H610
-
M.2 Slot
1
-
Hukommelses slots
2 x DIMM, DDR4
-
Maksimal RAM-frekvens
3.2GHz
-
Max hukommelse understøttet
64GB
-
Form Factor
micro ATX
|
H610MHP
Features:
- Supports 12th/ 13th Generation Intel Core™ Processor
- Intel H610 single chip architecture
- Supports 2-DIMM DDR4- 1866/ 2133/ 2400/ 2666/ 2933/ 3200 up to 64 GB Memory
- Supports PCIe 4.0
- Supports PCIe M.2 3.0 (32Gb/s)
- Supports HDMI 4K2K
- Supports USB 3.2 Gen1
Specifications:
Chipset
CPU SUPPORT - Support for 12th/ 13th Generation Intel Core™ i9/ i7/ i5/ i3 processors and Intel Pentium processors/ Intel Celeron processors in the LGA1700 package
MEMORY - Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666/ 2933/ 3200
- 2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
- Each DIMM supports non-ECC 4/8/16/32GB DDR4 module
- Support Intel Extreme Memory Profile (XMP) memory modules
INTEGRATED VIDEO - Supports DX12
- Supports HDCP
STORAGE - Total supports 1x M.2 socket and 4 x SATA III (6Gb/s) ports
- 4 x SATA III Connector (6Gb/s)
- 1 x M.2 (M Key) Socket (M2_PCIEG3_32G_ SATA):
- Supports M.2 Type 2240 /2260 /2280 SSD module
- Supports PCI-E 3.0 x4 (32Gb/s) & SATA SSD
LAN - Intel I219V
- 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
AUDIO CODEC - ALC897
- 7.1 Channels, High Definition Audio
USB - 4 x USB 3.2 (Gen1) ports (2 on rear I/Os and 2 via internal headers)
- 8 x USB 2.0 ports (4 on rear I/Os and 4 via internal headers)
EXPANSION SLOT - 1x PCIe 3.0 x1 Slot
- 1x PCIe 4.0 x16 Slot
REAR I/O - 1 x PS/2 Keyboard/Mouse Port
- 1 x HDMI
- 1 x VGA Port
- 2 x USB 3.2 (Gen1) ports
- 4 x USB 2.0 ports
- 1 x LAN port
- 3 x Audio Jack
INTERNAL I/O - 4 x SATA III Connectors (6Gb/s)
- 2 x USB 2.0 Headers (each header supports 2 USB 2.0 ports)
- 1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
- 1 x 8-Pin Power Connector
- 1 x 24-Pin Power Connector
- 1 x CPU Fan Connector
- 1 x System Fan Connector
- 1 x Front Panel Header
- 1 x Front Audio Header
- 1 x Internal Stereo Speaker Header
- 1 x Clear CMOS Header
- 1 x COM Port Header
- 1 x TPM Header
H/W MONITORING - CPU / System Temperature Monitoring
- CPU / System Fan Monitoring
- Smart / Manual CPU Fan Control
- CPU/DDR Voltage Monitoring
DIMENSION - Micro ATX Form Factor Dimension: 20.8cm x 23.6cm ( W x L )
OS SUPPORT - Supports Windows 10 (64bit) / 11(64bit)
BUNDLE SOFTWARE
ACCESSORIES - 2 x SATA Cable
- 1 x I/O Shield
- 1 x DVD Driver
- 1 x Quick Guide
