| PERFORMANCE |
| Processor | Intel® Core™ i3-13100, 4C (4P + 0E) / 8T, P-core 3.4 / 4.5GHz, 12MB |
| Graphics | Integrated Intel® UHD Graphics 730 |
| Chipset | Intel® B660 Chipset |
| Memory | 1x 8GB UDIMM DDR4-3200 |
| Memory Slots | Two DDR4 UDIMM slots, dual-channel capable |
| Max Memory | Up to 64GB DDR4-3200 |
| Storage | 256GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 |
| Storage Support | Up to two drives, 1x 3.5" HDD + 1x M.2 SSD
• 3.5" HDD up to 2TB
• M.2 SSD up to 1TB |
| Card Reader | None |
| Optical | None |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC623-CG codec |
| Speakers | 1Wx1 |
| Power Supply | 180W 85% |
| DESIGN |
| Keyboard | USB Calliope Keyboard, Black, Nordic (DK/FI/NO/SV) |
| Mouse | USB Calliope Mouse, Black |
| Expansion Slots | - One PCIe® 4.0 x16, low-profie (length < 167.65mm, height < 68.90mm)
- One PCIe® 3.0 x1, low-profie (length < 167.65mm, height < 68.90mm)
- Two M.2 slots (one for WLAN, one for SSD)
|
| Case Color | Black |
| Stand | None |
| Pen | Pen Not Supported |
| Form Factor | SFF (7.4L) |
| Dimensions (WxDxH) | 100 x 308 x 274.8 mm (3.9 x 12.1 x 10.8 inches) |
| Weight | Around 4.5 kg (9.9 lbs) |
| CONNECTIVITY |
| Ethernet | Integrated 100/1000M |
| WLAN + Bluetooth | None |
| WWAN | Non-WWAN |
| Front Ports | - 1x USB-C® 3.2 Gen 1 (support data transfer and 5V@3A charging)
- 2x USB 3.2 Gen 1
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
|
| Rear Ports | - 2x USB 2.0
- 2x USB 3.2 Gen 1 (one supports Smart Power On)
- 1x HDMI® 2.1 TMDS
- 1x DisplayPort™ 1.4
- 1x VGA
- 1x Ethernet (RJ-45)
- 1x line-out (3.5mm)
|
| Optional Rear Ports (configured) | None |
| Monitor Cable | None |
| SECURITY & PRIVACY |
| Security Chip | Discrete TPM 2.0, TCG certified |
| Fingerprint Reader | No fingerprint reader |
| Physical Locks | - Kensington® Security Slot™, 3 x 7 mm
- Padlock Loop
|
| Smart Cable Clip | None |
| Chassis Intrusion Switch | Chassis Intrusion Switch |
| MANAGEABILITY |
| System Management | Non-vPro® |
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 1Y Onsite from 1Y Depot WHB (CPN), CO2 Offset 1 ton (2nd Generation Carbon Offset Projects) |
| CERTIFICATIONS |
| Green Certifications | - ErP Lot 3
- RoHS compliant
- TCO Certified
|
| SOFTWARE |
| Operating System | Windows® 11 Pro, Nordic (DK/FI/SV/NO/EN) |
| Bundled Software | None |
| ACCESSORIES |
| Bundled Accessories | None |
| MODEL INFORMATION |
| Model | 12JH008MMX |
| Country/Region | Sweden |
| TopSeller | Yes |
| EAN / UPC / JAN | 0197531416933 |
| Announce Date | 2024-01-11 |
| End of Support | 2029-09-26 |
